PVC Power Cable 2.5mm2 Copper Conductor Low Voltage CE Certified

Brand Name:	Yuanhui
Model Number:	YH-1
MOQ:	500
Price:	$1-15

Detail Information

Product Description

Detail Information

Place of Origin:

Shandong, China

Insulation Material:

Conductor Material:

Copper

Jacket Material:

Color:

Black

Core Options:

11core, 32core, 3core

Voltage Rating:

Low Voltage

Nominal Section:

2.5mm², 1.5mm²

Max Diameter:

10.6mm (2 X 2.5)

DC Resistance:

7.98 Ω/km (2 X 2.5)

Insulation Resistance:

0.009 MΩ·km (2 X 2.5)

Carrying Capacity:

27A (2 X 2.5)

Cable Weight:

137kg/km (2 X 2.5)

Temperature Limit:

70ºC (standard), 105ºC (specific)

Rated Voltage:

300/500V, 450/750V

Armour Type:

Steel Or Customized

Highlight:

PVC power cable 2.5mm2 copper conductor

low voltage PVC power cable

CE certified PVC power cable

Product Description

Electric Wire 2.5mm² Electrical Wire - Heat Resistant Copper Conductor PVC Electrical Wire

Product Specifications

Attribute	Value
Insulation Material	PVC
Type	LOW VOLTAGE
Application	Construction
Conductor Material	Copper
Jacket	PVC
Color	Black
Standard	GB, IEC
Core	11core, 32core, 3core
Voltage	Low Voltage
MOQ	1000 Meters
Sample	Available
Armour	Steel or customized
Certificate	CE

Product Description

RVV H05VV-F FLEXIBLE BUILDING ELECTRIC AUTOMOTIVE VULCANIZADO AUDIO SPEAKER CABLE

Product Standards

The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005, GB/T5023-2008, JB/T8734-2012

Key Features

Uo/U is 300/500V 450/750V
Long-term allowable temperature of the cable: The allowable temperature of 105 Cable should not exceed 105ºC, the allowable temperature of other models should not exceed 70ºC

Applications

RVV is suitable for the laying of power units, fixed wiring, household appliances, instruments and telecommunications equipment with rated voltages of 450/750V and below
RVV can be used in places with high safety, environmental protection and flame retardant requirements such as high-rise buildings

Technical Specifications

Voltage (V)	Nominal Section (mm²)	Top Limit of Overall Diameter (mm)	Maximum DC Resistance 20℃	Minimum Insulation Resistance 70℃	Recommended Carrying Capacity (A)	Reference Weight (KG/KM)
300/300	2 X 0.5	5.9	3.9	0.012	10	37
300/300	2 X 0.75	6.3	26.0	0.01	13	47
300/300	3 X 0.5	6.3	39.0	0.012	8	44
300/300	3 X 0.75	6.7	26.0	0.01	10	58
300/300	2 X 0.75	7.2	26.0	0.011	13	58
450/750	2 X 1.0	7.5	19.5	0.01	16	66
450/750	2 X 1.5	8.6	13.30	0.01	20	89
450/750	2 X 2.5	10.6	7.98	0.009	27	137
450/750	2 X 4	12.4	4.95	0.007	38	205
450/750	2 X 6	12.4	3.30	0.006	50	280

Company Profile

Packing & Delivery

Our delivery time needs 5~10 days after receiving your payment. Please confirm all the detailed information so we can arrange your order as soon as possible!

Frequently Asked Questions

Q1: Are you trading company or manufacturer?

A1: We are manufacturer.

Q2: Do you have your own R & D team?

A2: Yes, we can customize products as your requirements.

Q3: How about the quality?

A3: We have the best professional engineer and strict QA and QC system.

Q4: Can we be your distributor?

A4: We are looking for distributor and agent all over the world.

Q5: How's the package?

A5: Normally are cartons, but also we can pack it according to your requirements.

Q6: How's the delivery time?

A6: It depends on the quantity you need, 1-25 days usually.
