99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance
  • name
  • name
  • name
  • name
  • name
  • name

99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance

Brand Name: Yuanhui
Model Number: BV
MOQ: 1000 meters
Price: $0.10/meters >=1000 meters
Detail Information
Product Description
Detail Information
Place of Origin:
Shandong, China
Certification:
CE CCC ISO
Type:
Insulated
Application:
Overhead
Conductor Material:
Copper
Conductor Type:
Solid
Insulation Material:
PVC
Rated Voltage:
450-750V
Product Name:
Copper Core PVC Insulation Wire
Conductor:
99.9% Pure Copper
Color:
Customer's Requirement
Insulation:
PVC Insulation Cable
Material:
PVC Copper
Jacket:
PVC Jacket
Size:
Customized Size
Packing:
100m/roll
Product Description
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 0
Product Description
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 1
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 2
Description:
1. standard IEC60227:1993, BS6004,VDE0281
2. 300/300v 300/500v 450/750v
3. PVC sheathed , color available
4. PVC temperature: -20 °C to +70 °C , also can be 90 °C and 105 °C PVC

Application:
The cable is suitable to be fixed wiring of power device, power lighting of home electric equipment and instrument, inner wiring of electric equipment, instrument, Electronic equipment, automation device etc.
Specification
Copper conductor PVC insulated flexible wire
标称截面（mm²）
Nominal section
线芯结构（mm）
Number/diameter of core
平均外径（mm）
Average dia
参考重量（kg/km)
Reference weight
20℃导体电阻<(Ω/km)
Conductor resistance at 20℃（Ω/km）
2.5
19/0.41
4.2
34.7
7.41
4
19/0.52
4.8
51.4
4.61
6
19/0.64
5.6
73.6
3.08
10
49/0.52
7.6
129
1.83
16
49/0.64
8.8
186
1.91
25
98/0.58
11.0
306
1.20
35
133/0.58
12.5
403
0.868
50
133/0.68
14.5
553
0.641
70
189/0.68
16.5
764
0.443
Company Profile
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 3
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 4
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 5
Shandong Jinyu Cable Co., Ltd. is located in Yanggu, the ancient city of a thousand years, the capital of Dongyi and the hometown of Wusong. It is adjacent to the Yellow River in the south, Shuicheng in the north, the German-Shanghai Expressway in the west, the Beijing-Kowloon High-speed Railway to the east, and the Beijing-Hangzhou Grand Canal running through the entire territory. The company integrates scientific research, production, and sales. It produces power cables, high-voltage cables, overhead cables, control cables, flame-retardant and fire-resistant cables, low-smoke and halogen-free cables and other products. The production equipment, complete testing equipment, dozens of varieties and hundreds of specifications of products are sold well at home and abroad and are trusted by users. The company adheres to the brand strategy, exerts the advantages of the Yanggu cable brand, and the Everbright Yanggu Yuanhui cable brand. All the staff wholeheartedly welcome you to come to the company for guidance and business negotiation!
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 6
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 7
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 8
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 9
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 10
99.9% Pure Copper Conductor Insulated BVR Electrical Wires for Optimal Performance 11
FAQ
1. who are we?
We are based in Shandong, China, start from 2014,sell to Eastern Asia(30.00%),South America(20.00%),Eastern Europe(10.00%),North America(10.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Wire and Cable,power cable,High voltage cable,Overhead cable

4. why should you buy from us not from other suppliers?
WE are manufacturer based of all kinds of different cable wires. The quality and price is competitively. We have professional sales manager and technology on producing.

5. what services can we provide?
Accepted Delivery Terms: null；
Accepted Payment Currency:null;
Accepted Payment Type: null;
Language Spoken:null
