XLPE Power Cable

4*240mm2 0.6Kv XLPE Power Cable Industrial PVC Jacket Cable Customized

All Category

Irrigation Cable

Mr. Mark

yuanhuimark@163.com

008618334797787

Contact Now

4*240mm2 0.6Kv XLPE Power Cable Industrial PVC Jacket Cable Customized

Brand Name:	Yuanhui
Model Number:	YJLV YJLV22 YJLV32
MOQ:	100 meters
Price:	$3.25/meters 100-999 meters
Packaging Details:	Ironwood shaft packing
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shandong, China

Certification:

ISO CCC CE

Insulation Material:

Lszh XLPE

Type:

LOW VOLTAGE High Voltage Medium Voltage

Application:

Industrial Construction Underground Power Station

Conductor Material:

Aluminum

Jacket:

Size:

As Requirments

Product Name:

YJV YJV22 YJV23 XLPE Power Cable

Rated Voltage:

1-35KV 0.6/1KV

Standard:

IEC 60227

Certificate:

ISO9001/CCC/CE

Core:

1/2/3/4/3+1/5/3+2/4+1

Package:

Iron-wooden Drum

Length:

Customized Meters

Armour:

SWA STA AWA ATA

Cross Section:

1.5mm-600mm2

Sample:

Availaible

Supply Ability:

50000 meters per week

Highlight:

240mm2 XLPE Power Cable

Industrial XLPE Power Cable

Customized PVC Jacket Cable

Product Description

4*240mm2 0.6/1kv Aluminum Conductor XLPE Insulated PVC Jacket Industrial Cable

Product Description

1. Conductor

The cable features a 4 - core configuration, with each core having a cross - sectional area of 240 square millimeters. The conductor material is aluminum. Aluminum is a popular choice for conductors due to its relatively good conductivity, lightweight, and cost - effectiveness. It allows for efficient transmission of electrical current.

2. Insulation

The insulation material used is cross - linked polyethylene (XLPE). XLPE offers excellent electrical insulation properties. It has a high dielectric strength, which means it can withstand high voltages without breaking down and allowing current to leak. This insulation helps to ensure the safety and integrity of the electrical signal transmission. It also provides resistance against moisture, chemicals, and mechanical stress to some extent.

3. Jacket

The cable is covered with a PVC (Polyvinyl Chloride) jacket. The PVC jacket serves multiple purposes. It provides a physical barrier that protects the inner insulation and conductor from external environmental factors such as abrasion, impact, and sunlight. It also offers some degree of fire resistance and is relatively easy to handle and install due to its flexibility

4. Voltage Rating

The cable has a voltage rating of 0.6/1kV. The 0.6kV represents the phase - to - neutral voltage, and 1kV represents the phase - to - phase voltage. This rating indicates the maximum voltage that the cable can safely carry during normal operation. It is designed to be used in industrial settings where electrical equipment typically operates within this voltage range.

5. Application in Industrial Settings

This type of cable is well - suited for industrial applications. It can be used for power distribution within industrial plants, connecting heavy - duty machinery, motors, and other electrical equipment. The robust construction of the cable, with its combination of aluminum conductor, XLPE insulation, and PVC jacket, makes it capable of withstanding the harsh conditions often found in industrial environments such as high - temperature areas, areas with chemical exposure, and locations with a lot of mechanical vibrations or movements.

Specification

Norminal cross section	Reference overall diameter of cable	Permissible A mpacily				Reference weight of cable
		A
		In air		In ground
MM²	MM	CU	AL	CU	AL	Kg/km
4X2.5	11.8	29	22	38	29	211	148
4X4	13.0	38	29	50	38	283	182
4X6	14.2	49	37	62	47	376	225
4X10	16.7	67	50	84	63	567	314
4X16	19.1	88	66	109	82	829	424
4X25	23.2	119	90	142	107	1249	618
4X35	25.5	146	110	170	129	1689	804
4X50	26.2	173	128	201	151	2146	916
4X70	28.9	218	164	245	185	2944	1219
4X95	32.5	271	201	294	223	3903	1559
4X120	35.9	315	234	333	253	4967	1956
4X150	40.2	366	272	374	321	6133	2413
4X185	44.4	422	315	421	481	7600	3008
4X240	49.4	486	377	489	425	9743	3784
4X300	56.0	569	440	555		12271	4716
4X400	67.9	686		628		16248

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Shandong Jinyu Cable Co., Ltd. is located in Yanggu, the ancient city of a thousand years, the capital of Dongyi and the hometown of Wusong. It is adjacent to the Yellow River in the south, Shuicheng in the north, the German-Shanghai Expressway in the west, the Beijing-Kowloon High-speed Railway to the east, and the Beijing-Hangzhou Grand Canal running through the entire territory. The company integrates scientific research, production, and sales. It produces power cables, high-voltage cables, overhead cables, control cables, flame-retardant and fire-resistant cables, low-smoke and halogen-free cables and other products. The production equipment, complete testing equipment, dozens of varieties and hundreds of specifications of products are sold well at home and abroad and are trusted by users.The company adheres to the brand strategy, exerts the advantages of the Yanggu cable brand, and the Ever bright Yanggu Yuanhui cable brand. All the staff wholeheartedly welcome you to come to the company for guidance and business negotiation!

FAQ

1. What is the minimum order quantity?

If you insist on buying one piece, or you only need one piece, we are likely to produce MOQ for you in batches.

2. How to get samples to check the quality? How long can I get the samples?

After the price is confirmed, samples can be provided for your evaluation. After confirming the sample details, the samples will be ready for delivery within 3-7 days, and sent to you by courier, and arrive within 3-5 days.

3. Which payment method does your company accept?

We accept wire transfer, letter of credit, Western Union.

4. What are your company's shipping terms and delivery time?

20-30 days for bulk, 5-10 working days for inventory.

5.Do you have a discount?

We will do our best to provide you with these services at the best price and quality service.
